Wireless Safety Edge Kits – Conductive Safety Edge for Automated Doors and Gates
The Wireless Safety Edge Kits feature a conductive safety edge designed specifically for ensuring reliable safety on industrial automated doors and gates. This pressure-sensitive sensor offers robust protection against accidental crushing or shearing at critical closing edges, safeguarding people, vehicles, and machinery from harm or damage.
The kit includes everything needed for effective implementation, including an optional rolling code radio receiver for secure wireless operation.
Key Features & Benefits:
-
Enhanced Safety: Pressure-sensitive design instantly detects obstructions at potential crush or shear points, minimising the risk of injury or equipment damage.
-
Wireless Convenience: Optional rolling code radio receiver enables secure wireless communication, simplifying installation and eliminating complex wiring.
-
Robust Construction: Made from durable TPE with IP65 rating (IP68 available on request), designed to withstand harsh industrial environments.
-
Versatile Installation: Ideal for various automated doors, gates, and other moving machinery, adaptable to industrial, commercial, or residential settings.
-
Easy Integration: Can connect up to 5 contact strips in series, with a maximum length of 100m, offering flexibility to meet diverse application requirements.
-
High Durability: Rated for up to 10,000 switching cycles, ensuring reliable, long-term performance even under heavy usage.
Technical Specifications:
| General Specification | Details |
|---|---|
| Stock Code | COND-KIT, COND-KIT-RADIO* |
| Material | TPE |
| Material Hardness | 68 Shore A |
| Standard Delivery Length | 25 m |
| Weight | 0.34 kg/m |
| Enclosure Rating | IP65 (IP68 available on request) |
| Mechanical Force | 500 N |
| Switching Cycles | 10,000 |
| Switching Angle | 2 × 45° |
| Actuation Resistance | ≤ 500 Ohm |
| Electrical Capacity | 24 V, 100 mA |
| Operating Temperature | -10 °C to 55 °C |
| Maximum Temperature Range | -25 °C to 75 °C |
| Maximum Series Connection | 5 Contact Strips |
| Maximum Combined Length | 100 m |
| Inactive End Region (Higher Force) | 30 mm |
| Connection Cables | LIY11Y 2×34mm, PUR Matte Black |
| Test Speed (Actuation) | 100 mm/s & 200 mm/s |
| Actuation Force | 42.3 N (100 mm/s), 51.3 N (200 mm/s) |
Actuation Distances:
| Test Speed | Actuation Distance | Overtravel to 250N | Overtravel to 400N | Overtravel to 600N |
|---|---|---|---|---|
| 100 mm/s | 4.5 mm | 12.5 mm | 14.5 mm | 16.5 mm |
| 200 mm/s | 5.5 mm | 11.5 mm | 13.5 mm | 15.5 mm |
Applications:
-
Automated gates and doors
-
Industrial machinery with moving components
-
Warehouse entrances
-
Commercial and industrial vehicle access points
The Wireless Safety Edge Kits deliver dependable and effective safety solutions tailored for automated doors and gates, ensuring compliance with rigorous safety standards and offering ease of installation and reliable operation.
