Timmer Brake - Roller Shutter Safety Brake (18mm shaft)

Timmer Brake - Roller Shutter Safety Brake (18mm shaft)

Net: £72.00
Incl. VAT: £86.40
Taxes included.
Delivery info
  • In-stock items: same-day dispatch when ordered before 1 pm, Monday–Friday, excluding bank holidays.
  • Other standard items: next working day dispatch.
  • Customised and bespoke items: individual lead times apply. Confirmation will be sent after ordering.
  • Free delivery on eligible orders over £300. Exclusions apply.
  • View delivery and collection details

Timmer Safety Brake – For DRS Motors, Roller Shutters & Industrial Doors
The Timmer Safety Brake is a high-quality, German-manufactured brake unit designed to provide reliable safety for roller shutters and industrial door systems. Specifically modified for DRS motors, this safety brake prevents uncontrolled curtain descent, ensuring compliance with UK and EU safety standards.

 Key Features & Benefits

  • No Spacing Plate Required:
    Modified exclusively for DRS motors, making installation faster and simpler.

  • High Safety Standards:

    • 200kg activation limit

    • Max torque: 147Nm

    • Fully resettable safety mechanism

    • TÜV tested, CE & UKCA certified

  • Durable German Engineering:
    Manufactured in Germany for consistent reliability and long service life.

  • Optional Micro-Switch:
    Available with factory-fitted microswitch for electrical safety integration.

  • Broad Shaft Compatibility:
    Stocked with shaft and discs to suit a wide range of tube sizes:

    • 60mm Octagonal

    • 70mm Octagonal

    • 90mm Round

    • 4" 16swg (97mm) Round

    • 4" 9swg (94mm) Round

  • Peace of Mind:
    Provides compliance with legal safety obligations for powered roller shutters and doors.

 Product Details

Feature Detail
Manufacturer Timmer (Germany)
Model/Ref DRSBRAKETIMMER
Activation Limit 200kg
Torque Capacity 147Nm
Bore Size 18mm square
Reset Function Fully resettable
Certifications TÜV Tested, CE & UKCA Certified
Options With or without microswitch
Tube Size Compatibility 60mm / 70mm Octagonal, 90mm Round, 4" Round (94mm/97mm)
View full details

FAQ's

Which system is the Timmer Brake - Roller Shutter Safety Brake compatible with?

The Timmer Brake - Roller Shutter Safety Brake is designed for use with a wide range of tube sizes: 60mm Octagonal 70mm Octagonal 90mm Round 4". Confirm your operator or door model matches before ordering to ensure a correct fit.

What is the Timmer Brake - Roller Shutter Safety Brake and what is it used for?

Timmer Safety Brake – For DRS Motors, Roller Shutters & Industrial Doors The Timmer Safety Brake is a high-quality, German-manufactured brake unit designed to provide reliable safety for roller shutters and industrial door systems.

When should this part be replaced?

Replace the Timmer Brake - Roller Shutter Safety Brake when you notice signs of wear such as noisy or uneven door movement, visible damage or play, or reduced performance. Fitting a fresh part also helps protect the surrounding components from further wear.

Does the Timmer Brake - Roller Shutter Safety Brake provide timmer safety brake – for drs motors?

Timmer Safety Brake – For DRS Motors, Roller Shutters & Industrial Doors The Timmer Safety Brake is a high-quality, German-manufactured brake unit designed to provide reliable safety for roller shutters and industrial door systems. Specifically modified for DRS motors , this safety brake prevents uncontrolled curtain descent, ensuring compliance with UK and EU safety standards.

Does the Timmer Brake - Roller Shutter Safety Brake provide no spacing plate required?

Modified exclusively for DRS motors , making installation faster and simpler.
