Re-Chargable Battery 12V 7Ah C20

12V 7Ah Rechargeable Battery – C20 Rated (Sealed Lead Acid)

The 12V 7Ah C20 Rechargeable Battery is a sealed lead acid (SLA) battery designed for dependable standby or cyclic use in a wide range of electronic systems. With a C20 capacity rating, this battery is optimised for 20-hour discharge applications, making it ideal for alarm systems, access control, door automation, UPS systems, and battery-backed power supplies.

Key Features & Benefits

• 12 Volt, 7Ah Capacity (C20 Rated)
  Provides 7 amp-hours of power over a 20-hour discharge cycle — ideal for systems requiring steady, long-duration output.

• Sealed, Maintenance-Free Design
  Valve Regulated Lead Acid (VRLA) construction ensures safe operation in any position (except inverted) with no need for topping up.

• Rechargeable & Long Life
  Designed for regular cycling and float charging, with excellent charge retention and recovery after deep discharge.

• Versatile Application
  Suitable for backup or primary power in security, access control, intercoms, fire alarms, and automation systems.

• F1 or F2 Terminal Options
  Available with standard 4.8 mm (F1) or 6.3 mm (F2) faston terminals to suit most common power supply and device connections.

Technical Summary

• Nominal Voltage: 12V DC

• Capacity: 7Ah @ C20 rate

• Battery Type: Sealed Lead Acid (VRLA / AGM)

• Terminals: Faston tabs (F1 or F2 – check variant)

• Dimensions (approx.): 151 mm (L) x 65 mm (W) x 94 mm (H)

• Weight: ~2.1kg

• Operating Environment: Indoor use, suitable for control panels or enclosures

• Typical Life Expectancy: 3–5 years (depending on usage and environment)
