GEM Electric Strike 12/24v DC Fail Safe/ Fail secure

GEM Electric Strike (12/24V DC) – Dual Voltage, Fail Safe/Fail Secure with Long & Short Faceplates

The GEM Electric Strike is a versatile, ANSI-style electric release, ideal for both wooden and metal door installations. Offering dual voltage compatibility (12V or 24V DC) and a switchable fail-safe or fail-secure operation, this electric strike is perfect for flexible and secure access control applications. The package includes interchangeable long and short faceplates to simplify installation and accommodate various door frame designs.

Product Overview:

The GEM Electric Strike provides secure, reliable locking and controlled access to doors within commercial and public buildings. Its adaptable design makes it an excellent choice where versatility in voltage and security mode is essential, offering quick and simple adjustments on-site.

Key Features & Benefits:

Dual Voltage Operation:

• Quickly switchable between 12V DC (250mA) or 24V DC (150mA), ensuring compatibility with various power supply systems.

Fail Safe or Fail Secure Modes:

• Easily selectable mode providing operational flexibility:

  • Fail Safe (unlocks if power is lost), recommended for emergency exits.

  • Fail Secure (remains locked if power is lost), suitable for secure areas.

ANSI-Style Design:

• Standard ANSI style ensures compatibility with a wide range of commercial door frames and hardware.

Reversible Installation:

• Can be installed for either left or right-handed doors, simplifying procurement and installation.

Complete Faceplate Options:

• Supplied with both long and short faceplates, making it adaptable for metal or wooden doors without additional modifications.

Optional Lip Extensions:

• Lip extensions available separately for wider frames or custom installations.

Technical Specifications:

• Operating Voltage: 12V DC or 24V DC (field selectable)

• Current Consumption:

  • 12V DC: 250mA

  • 24V DC: 150mA

• Security Modes: Fail Safe or Fail Secure (switchable)

• Faceplate Options: Includes both long and short faceplates

• Door Compatibility: Suitable for wooden and metal doors

• Reversible Design: Yes (left/right door applications)

• ANSI Standard: Yes
