BEA VIO-ST Active Infrared Presence Safety Sensor

VIO-ST Active Infrared Presence Safety Sensor – EN16005 Compliant

Sidescreen safety sensor or Threshold only safety.

The VIO-ST Presence Sensor provides advanced pedestrian safety through a double failsafe active infrared curtain system, offering maximum protection from accidental door contact. Designed specifically to prevent pedestrian collisions with automatic doors, this sensor creates a comprehensive three-dimensional detection area without relying on traditional safety beams. Ideal for high-traffic environments, the VIO-ST ensures reliable performance and compliance with rigorous safety standards including EN16005 and EN ISO 13849-1.

Key Features & Benefits:

• Enhanced Pedestrian Safety:
  Utilises two curtains of 24 infrared detection spots each, ensuring failsafe protection compliant with EN16005 safety standards.

• Three-Dimensional Coverage:
  Infrared curtain technology creates a volumetric safety zone, preventing pedestrian contact with moving door leaves.

• Easy Configuration & Adjustment:
  DIP-switch settings allow quick, simple customisation. Curtain width adjustable through interchangeable prisms, offering configurations of either 12 or 24 spots.

• Robust Reliability & Immunity:
  Advanced infrared self-adaptive technology guarantees optimum performance even in challenging environmental conditions.

• Flexible Mounting Height:
  Suitable for installations between 1.8m and 3m, making it versatile for various doorway setups.

• Long Operational Life:
  Designed with an expected lifetime of 20 years, ensuring reliable long-term protection and reduced maintenance costs.

Technical Specifications:

• Detection Method: Active Infrared with Background Analysis

• Infrared Spot Count: 24 spots per curtain (2 curtains total)

• Mounting Height: 1.8 m – 3 m adjustable

• Supply Voltage: 12 V - 30 V DC (-5%/+10%) SELV compatible

• Power Consumption: < 1.6 W

• Temperature Operating Range: -25 °C to +55 °C

• Output Type: Solid-state relay (potential-free, polarity-free)

  • Max Contact Current: 100 mA

  • Max Contact Voltage: 42 V AC/DC

• Response Time: Typical response <256 ms; Max presence detection: 30 seconds

• Test Input Sensitivity:

  • Log. L: < 1 V

  • Log. H: > 10 V (max. 30 V)

• Protection Rating: IP54 (suitable for indoor and outdoor installations)

• Noise Level: < 70 dB

• Angle Adjustment: -4° to +4° adjustable

Compliance & Certification:

• EN 16005:2012

• EN 12978:2009

• EN IEC 62061:2005 SIL2

• EN 61496-1:2012 ESPE Type 2

• EN ISO 13849-1:2008 Pl «c» CAT.2 (Sensor monitoring required once per door cycle)

• EN 61000-6-2; EN 61000-6-3; EN 50581

The VIO-ST Active Infrared Sensor is the optimal choice for ensuring superior pedestrian safety, providing robust, fail-safe protection for automatic doors in high-use and safety-critical environments.
