Assa Abloy - SW100 Push, Black

Assa Abloy SW100 – Push Version with Black Endcaps and Arm

The Assa Abloy SW100 is a low-energy automatic swing door operator, engineered for quiet, safe, and efficient operation in public and commercial buildings. This push-arm variant features a stylish finish with black endcaps and a black arm, making it ideal for modern environments where aesthetics and functionality are equally important.

Comes with an SA Card for safety. SI Cards are available separately.

Key Features & Benefits

• Push Configuration
  Designed for mounting on the hinge side of the door to push the door leaf open. Suitable for outward-opening applications.

• Black Endcaps and Arm Assembly
  Offers a clean, contemporary appearance. Ideal for interior or exterior doors where a sleek, modern finish is desired.

• Low-Energy Operation
  Compliant with accessibility standards for assisted opening without full automation. Operates quietly and safely in environments such as care homes, offices, or healthcare settings.

• Fully Adjustable Settings
  Control opening and closing speeds, hold-open time, and manual push force to suit site requirements.

• Compact and Reliable Design
  Slimline operator body suitable for surface mounting on single or double leaf doors. Built for high reliability and low maintenance.

• Safety and Compliance
  Integrates with presence sensors, safety devices, and access control systems. Suitable for BS EN16005-compliant installations.

Technical Summary

• Operator Type: Electro-mechanical swing door operator

• Mounting: Push-side installation (hinge side)

• Finish: Black endcaps and black articulated arm

• Power Supply: 230V AC input / 24V DC motor

• Door Weight Capacity: Up to 250 kg (dependent on settings and conditions)

• Opening Angle: Up to 115°

• Handing: Non-handed (configurable left or right)
